VELDURO Rogue emtb
FRAME ONLY
Build it your way with the Velduro Rogue FRAME ONLY option!
our mid-pivot, i-track patented full carbon UDH e-MTB Frame is powered by the DJI Avinox drive system, 800w battery.
Riders wanted a frame only option! we listened! lets go!
Rogue frame only: RRP $8,499 NZD
NZ customers: To secure please full out preorder order form with your location in NZ. We will be in touch with 30% deposit invoice asap.
International customers: Thank you for your patience and support, we are making significant progress on getting Velduro onto your trails. More details to come.
-
16T CNC stainless steel idler
Chain wheel 7050, heat treated and hard anodised Lekkie one piece custom 34T. (Sram and Shimano compatible)
chain guide included
FSA no.42 headset
12x148 rear thru axle
UDH Hanger
Seat post clamp
Cable lugs
Dji Avinox M1 Motor
800wh Battery
2 inch smart screen
Remotes
DJI speed sensor
4A Charger
Pre cabled
DJI Avinox chainwheel spider with lock
DJI Avinox cranks 155mm
SPECification /compatibility for custom build
-
external wired headset, dia top 42mm/bottom 52mm
-
1.5T, 160-180mm travel fork
Shock 205mm x 65mm(TR),bushings as M8*30mm
65mm travel shock max to 172mm rear travel
62.5mm trvael shock as 160mm rear travel
-
Dia 31.6mm, insert depth 280mm on M size frame
Dropper Travel Suggestions - S: 180mm, M&L: 210mm, XL:240mm
Dropper cable length: 1200mm
-
Frame rear brake flat mount 200mm
Frame brake cable 950mm
Rear brake cable 1700mm
-
Chainwheel: Custom designed Lekkie 34T - itrack optimised and tuned for 34T only
Crank: up to 165 length, min offset:25mm
UDH derailleur suitable
1x shifting only
Shimano and Sram compatible
Manual Shift cable length 2000mm
-
Front hub: depends on the fork, normally 15 x 110mm
Rear hub: 12x148 boost
Front rim: 29’(700c) rim
Rear rim: 29’(700c)or 27.5 (650B) rim
Front tyre: max 29’x 2.6
Rear tyre: max to 29’x2.6 or 27.5x2.6
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | Eff. Seattube Length (mm) | 390 | 410 | 430 | 465 |
| B | Headtube Angle (°) | 63.5 | 63.5 | 63.5 | 63.5 |
| C | Eff. Toptube Length (mm) | 573.6 | 599.6 | 623.9 | 652 |
| D | Reach (mm) | 440 | 466 | 485 | 515 |
| E | Act. Seattube Angle (°) | 75.5 | 75.5 | 75.5 | 75.5 |
| F | Seattube Offset (mm) | 30 | 30 | 30 | 30 |
| G | Eff. Seattube Angle (°) | 78.1 | 78.1 | 78 | 77.9 |
| H | Chainstay Length (mm) | 440 | 440 | 440 | 440 |
| I | BB Drop at Rear Wheel (mm) | 12 | 12 | 12 | 12 |
| J | BB Drop at Front Wheel (mm) | 31 | 31 | 31 | 31 |
| K | Headtube Length (mm) | 110 | 110 | 120 | 125 |
| L | Axle to Crown (mm) | 584 | 584 | 584 | 584 |
| M | Fork Offset (mm) | 44 | 44 | 44 | 44 |
| N | Trail (mm) | 140.1 | 140.1 | 140.1 | 140.1 |
| O | Stack (mm) | 632.5 | 632.5 | 641.4 | 645.9 |
| P | Wheelbase (mm) | 1230 | 1265 | 1300 | 1335 |
| Recommended Height (CM) | 160-172 | 172-182 | 180-188 | 185-195 | |
Rogue frame only: RRP $8,499 NZD
PrE ORDERS are NZ only - worldwide soon!
Secure the Velduro Rogue with a fully refundable 30% deposit. You can choose to have your bike freighted directly or to a bike retailer in your area.
Fill out the form, and we'll contact you within 72 hours to secure your bike and arrange secure deposit payment.
NB: This is only for NZ customers.
Arrival Dates:
October for frame only
November 2025 for full builds
We will be in touch to discuss supporting you in the build process.
30% refundable deposit will be invoiced directly, payment remainder will be invoiced on delivery
